Working as a standalone solution, GV-AS100 is a card reader and also a single door controller. It is possible to add one more card reader to GV-AS100 for entry and exit applications. GV-AS100 has the capability to store up to one thousand cards. When GV-AS100 is being used as a standalone unit the programming is either done on the keypad or from the software GV-ASManager through the RS-485 connection.
An economic solution for access control, GV-AS100 is suitable for controlling doors, parking gates and access to elevator call buttons.
Features
Specifications
Options
Packing List
1,000 / 40,000 cards (standalone / networked or RS-485 mode)
Easy programming from keypad
Anti-Passback (APB) support
Built-in 3 digital inputs and 2 relay outputs
One Weigand output (26 ~ 64 bits) and 1 RS-485 interface for extra reader programming
Built-in Tampering Alarm
Built-in 13.56MHz Reader
Specifications
System Requirements
GV-ASManager Version
GV-ASManager V2.1 or later
Hardware
CPU
8-bit RISC microprocessor
Number of User Cards
1,000 / 40,000 cards (standalone / networked or RS-485 mode)
Frequency
13.56 MHz for ISO14443A (MIFARE DESFire,?MIFARE Plus and?MIFARE Classic)
Event Buffer
65,536 events and log data
Power
100 ~ 240V AC, 50 ~ 60Hz
Wiegand Interface
1 Wiegand interface, 26 ~ 64 bit format
12V DC Power Supply, 200mA
Communication Protocol
RS-485
RS-485 Interface
1 RS-485 interface only for 1 GV-Reader or GV-GF Fingerprint Reader
Digital I/O
Input
3 inputs, dry contact, NO / NC
Output
2 outputs
Supported ID Format
Built-in reader reads UID only
Operating Temperature
0 ~ 65°C / 32 ~ 149°F
Operating Humidity
10 ~ 90% RH (non-condensing)
Dimensions (W x H x D)
95 x 108 x 23 mm / 3.74 x 4.25 x 0.91 in
Weight
250 g / 0.55 lb
Ingress Protection
IP54
Certification
CE, FCC, RoHS
Note:
1.?RS485 interface only supports GeoVision readers, while Wiegand interface supports both GeoVision and 3rd party readers (Wiegand 26~64 Bits).
2.?GV-AS Controller does not support 3rd party access control software
3. GV-AS100?is a controller with a built-in card reader. GV-AS100?cannot be used as an independent card reader.
4.?Specifications are subject to change without notice.
Optional devices can expand the capabilities and versatilities of your GV-AS Controllers. Consult your sales representative for more information.
GV-Reader 1251 is a card reader that uses a 125 kHz frequency. It has both Wiegand and RS-485 outputs that can be connected to any standard access control panel.
GV-Reader 1351 V2 is a card reader that uses a 13.56 MHz frequency. It has both Wiegand and RS-485 outputs that can be connected to any standard access control panel.
GV-RK1352 is a card reader with keypad that uses a 13.56 MHz frequency. The reader has both Wiegand and RS-485 outputs that can be connected to any standard access control panel.
GV-R1352 is a card reader that uses a 13.56 MHz frequency. The reader has both Wiegand and RS-485 outputs that can be connected to any standard access control panel.
GV-DFR1352 is a card reader that uses a 13.56 MHz frequency. The reader has both Wiegand and RS-485 outputs that can be connected to any standard access control panel.
The reader supports three operation modes: Fingerprint Only, Fingerprint + Card and Card Only. In Fingerprint Only mode, the fingerprints are enrolled through GV-ASManager. In Fingerprint + Card mode, the fingerprint templates are stored on the user card. In Card Only mode, the users only need to swipe the card to be granted access. Readers with optical and capacitance sensors are available.
GV-CR420 is a card reader with a built-in 4MP wide angle IP camera. The card reader recognizes identification cards and transmits live view through network connection.
Only works with GV-AS100 / 110 / 120. The device can add Network function, 1 Wiegand interface, 8 additional inputs and outputs to GV-AS100, GV-AS110 and GV-AS120.
Only works with GV-AS100 / 110 / 120. GV-Hub V2 can convert the standard RS-232 signal of up to 4 controllers to RS-485, allowing the controllers to connect to computers.
Only works with GV-AS100 / 110 / 120. GV-COM V2 can convert the standard RS-232 signal of one controller to RS-485, allowing the controller to connect to a computer.
Only works with GV-AS100 / 110 / 120. GV-COM V3 can convert the standard RS-232 signal of one controller to RS-485, allowing the controller to connect to a computer.
Only works with GV-AS100 / 110 / 120. GV-Net / IO Card can convert the standard RS-232 signal of one controller to RS-485, allowing the controller to connect to a computer.
The push button switch can be integrated with access control system, allowing door exit by momentarily activating or deactivating the electric locking device. Both American standard and European standard push buttons are available.
GV-AS ID Cards and GV-AS ID Key Fobs are ideal for business and residential environment, where access control is important for security reasons. 125 kHz and 13.56 MHz cards and key fobs are available.
